Pure molybdenum product
Molybdenum - universal metal
People learned molybdenite long ago. Only its resemblance to galena and
graphite played a bad joke. All three minerals were called the same -
Molybdaena.
The main properties of molybdenum
The metal has a high specific gravity of 10.2 g / cm3, an important
property of molybdenum is its refractoriness - this is a consequence of
the strong interatomic bonds of the element due to the unfilled internal
electron shell. The result of the physical properties inherent in the
metal is a number of advantages that molybdenum and its alloys possess:
heat resistance;
good electrical conductivity;
low thermal expansion;
high mechanical strength.
In the last paragraph, the metal is slightly inferior to tungsten, but
surpasses it in the availability of pressure treatment. Another
important specificity of the substance, which provided it with a place
as an alloying additive to other metals and their alloys, is its high
anticorrosive ability.
Molybdenum is a chemical element with atomic number 42 in the periodic
table, where it is a close neighbor to tungsten and chromium. Molybdenum
is characterized by a light gray color and a metallic sheen. The most
important properties inherent in this element are its refractoriness. In
addition, element No. 42, as well as the alloys in which it is present,
have heat resistance, thermal expansion, high electrical conductivity
and mechanical strength, which undoubtedly are advantages. It should be
noted that molybdenum takes the second place in strength, giving way to
the leader of tungsten, but ahead of it in the availability of pressure
treatment.
In most cases, molybdenum acts as a binder to other metals and their
alloys due to its anti-corrosion properties.
Some characteristics of the item:
density 10.2 g / cm^3;
the crystal lattice is body-centered, cubic;
melting point 2623 ° C;
paramagnetic;
Mohs hardness 4.5.
The chemical properties are largely due to oxidation states: +2, +3, +4,
+5, +6 (the latter is the most stable).
The metal practically does not react with hydrogen and nitrogen.
Under normal conditions, molybdenum does not react with air gases. It
starts to oxidize when heated above 400 ° C.
When exposed to reducing agents in a slightly acidic environment, it
forms molybdenum blue. These substances are used as dyes (for example,
in dyeing silk).
How to get Molybdaenum
Obtaining molybdenum can be divided into several stages:
Flotation enrich the ore. The result is molybdenum concentrates, their
three grades.
Production from MoO3 concentrates, the so-called “Cinder”, pure
molybdenum anhydride is isolated from cinder by distillation or chemical
processing. The purity of the product is not less than 99.975%.
Molybdenum powder with a grain size of 0.5-2 microns is obtained by
reduction of anhydride with hydrogen.
Application: from light bulb to rocket
Most of the products from molybdenum are consumed by electronics.
The use of metal in rocket technology is increasing: for lining rockets
and capsules, in nozzles of rocket engines, in solid fuel rockets.
Molybdenum wire is used for the production of thermocouples,
incandescent lamps, and heaters for high-temperature electric furnaces.
Molybdenum tapes and wire are in demand in the lighting industry, from
which electrodes for melting glass are made.
The use of molybdenum and its alloys in nuclear energy, in the
production of cooling pipelines, and shells of fuel assemblies is
widespread.
More than 2/3 of the metal produced is used in metallurgy as an alloying
additive to steel.
Molybdenum sulfide is an excellent high-temperature lubricant for parts,
it is coated with bullets, it is used in the manufacture of ceramic
products as an additive in clay (to obtain blue or red colors)..
;
.
molybdenum
Cobalt
Iron
Carbon
Sulfur
Copper
Zinc
Lead
Total Impurities
99.99
<0.00002
0.002
<0.01
0.0002
0.00005
0.00005
0.00002
<0.01
Diam
thickness
length
width
purity
Details
Foil
0.03mm -0.8mm
>3000mm
2mm-150mm
99.99%
Details
sheet
0.03mm-50mm
100mm
100mm
99.99%
Details
wire
0.025mm
-0.05mm
7000-8000m
99.99%
Details
Stab
2.0mm
-150mm
<1000mm
99.99%
Details
powder
50nm- 20μm
99.99%
Details
Pellets
6mm-13mm
99.99%
Details
granules
6mm-13mm
99.99%
Details
Sputter
target
3mm-300mm
O30--2000mm
99.99%
Details
crucible
30ml-50ml
99.9%
Details
mesh
0.05-2mm
hole:0.3X0.6mm, 0.5X1mm
............20X40mm
99.9%
Details
Molybdenum - universal metal
People learned molybdenite long ago. Only its resemblance to galena and
graphite played a bad joke. All three minerals were called the same -
Molybdaena.
The main properties of molybdenum
The metal has a high specific gravity of 10.2 g / cm3, an important
property of molybdenum is its refractoriness - this is a consequence of
the strong interatomic bonds of the element due to the unfilled internal
electron shell. The result of the physical properties inherent in the
metal is a number of advantages that molybdenum and its alloys possess:
heat resistance;
good electrical conductivity;
low thermal expansion;
high mechanical strength.
In the last paragraph, the metal is slightly inferior to tungsten, but
surpasses it in the availability of pressure treatment. Another
important specificity of the substance, which provided it with a place
as an alloying additive to other metals and their alloys, is its high
anticorrosive ability.
Molybdenum is a chemical element with atomic number 42 in the periodic
table, where it is a close neighbor to tungsten and chromium. Molybdenum
is characterized by a light gray color and a metallic sheen. The most
important properties inherent in this element are its refractoriness. In
addition, element No. 42, as well as the alloys in which it is present,
have heat resistance, thermal expansion, high electrical conductivity
and mechanical strength, which undoubtedly are advantages. It should be
noted that molybdenum takes the second place in strength, giving way to
the leader of tungsten, but ahead of it in the availability of pressure
treatment.
In most cases, molybdenum acts as a binder to other metals and their
alloys due to its anti-corrosion properties.
Some characteristics of the item:
density 10.2 g / cm^3;
the crystal lattice is body-centered, cubic;
melting point 2623 ° C;
paramagnetic;
Mohs hardness 4.5.
The chemical properties are largely due to oxidation states: +2, +3, +4,
+5, +6 (the latter is the most stable).
The metal practically does not react with hydrogen and nitrogen.
Under normal conditions, molybdenum does not react with air gases. It
starts to oxidize when heated above 400 ° C.
When exposed to reducing agents in a slightly acidic environment, it
forms molybdenum blue. These substances are used as dyes (for example,
in dyeing silk).
How to get Molybdaenum
Obtaining molybdenum can be divided into several stages:
Flotation enrich the ore. The result is molybdenum concentrates, their
three grades.
Production from MoO3 concentrates, the so-called “Cinder”, pure
molybdenum anhydride is isolated from cinder by distillation or chemical
processing. The purity of the product is not less than 99.975%.
Molybdenum powder with a grain size of 0.5-2 microns is obtained by
reduction of anhydride with hydrogen.
Application: from light bulb to rocket
Most of the products from molybdenum are consumed by electronics.
The use of metal in rocket technology is increasing: for lining rockets
and capsules, in nozzles of rocket engines, in solid fuel rockets.
Molybdenum wire is used for the production of thermocouples,
incandescent lamps, and heaters for high-temperature electric furnaces.
Molybdenum tapes and wire are in demand in the lighting industry, from
which electrodes for melting glass are made.
The use of molybdenum and its alloys in nuclear energy, in the
production of cooling pipelines, and shells of fuel assemblies is
widespread.
More than 2/3 of the metal produced is used in metallurgy as an alloying
additive to steel.
Molybdenum sulfide is an excellent high-temperature lubricant for parts,
it is coated with bullets, it is used in the manufacture of ceramic
products as an additive in clay (to obtain blue or red colors)..
;
.
| molybdenum | Cobalt | Iron | Carbon | Sulfur | Copper | Zinc | Lead | Total Impurities | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 99.99 | <0.00002 | 0.002 | <0.01 | 0.0002 | 0.00005 | 0.00005 | 0.00002 | <0.01 |
| Diam | thickness | length | width | purity | Details | ||
|---|---|---|---|---|---|---|---|
|
|
Foil | 0.03mm -0.8mm | >3000mm | 2mm-150mm | 99.99% | Details | |
|
|
sheet | 0.03mm-50mm | 100mm | 100mm | 99.99% | Details | |
|
|
wire | 0.025mm -0.05mm |
7000-8000m | 99.99% | Details | ||
|
|
Stab | 2.0mm -150mm |
<1000mm | 99.99% | Details | ||
|
|
powder | 50nm- 20μm | 99.99% | Details | |||
|
|
Pellets | 6mm-13mm | 99.99% | Details | |||
|
|
granules | 6mm-13mm | 99.99% | Details | |||
|
|
Sputter target |
3mm-300mm | O30--2000mm | 99.99% | Details | ||
|
|
crucible | 30ml-50ml | 99.9% | Details | |||
|
|
mesh | 0.05-2mm | hole:0.3X0.6mm, 0.5X1mm ............20X40mm |
99.9% | Details | ||
